Description
RH MACH II The RH Mach III Pinspotter features a more efficient transformer that provides a wider range of welding capabilities. The Heavy Duty Vibrator Bowl and base weld pins up to 2’’ and the optional manual feed accommodates pins up to 4’’ on 4’’ insulation A floating upper weld tip and an optional lift kit are among some of the improvements to this Pinspotter. The RH Mach III also features a notch on the support bar to easily accommodate TDC/TDF duct. The ability to move the trolley instead of the ductwork minimizes material handling. This feature coupled with utilization of welded pins will insure your shop of a cost efficient, quality product.
specifications
- Input voltage: 230V, single phase, 60 amp service
- Air Requirements: Input pressure of 80 psi
- Throat Size: A 60” throat allows fasteners to be placed up to 1.5” from each edge of a 5’ sheet without repositioning
- Rib Pin Capacity: The vibrator bowl holds approximately 1,000, 1 inch fasteners. Fasteners of .5” to 2” in length may be fed automatically
features
- Easy manual loading/unloading feature for 3” & 4” weld pins
- New heavy duty vibrator base & bowl for automatic feeding of up to 2” pins
- Airless vibrator sensor reduces noise and prevents wasted air usage
- Diagnostic Operations Display with Dual Controls
- Silicone weld cable for better grounding and durability
- TDC/TDF Notch
- Wider mouth design for welding up to 4” duct liner with 4” weld pins
- An optional machinery lift kit is also available for a custom ergonomic work space
- Redesigned more efficient single transformer for a wider range of welding capabilities
