Model 10 Roto-Die
The Model 10 Roto-Die is a 10-foot light gauge Hydraulic sheet metal bender and an industry standard for many HVAC duct shops. We proudly offer a wide selection of replacement parts for this versatile machine, including disappearing pin & spring assemblies, tie rods, ram return springs and foot pedal cables. If you are unsure about the parts you need, please contact us for assistance.
Model 10 Roto-Die
-
RD-01350 Hub Position Handle with Detent (RD10/15)
$81.00 -
RD-00308 Hydraulic Cylinder (RD10)
$1,462.50 -
RD-00312 Brass Gib Insert - OLD Style FLAT (RD10/15)
$73.00 -
RD-00314 Upper Rod Block (RD10)
$203.00 -
RD-00317 Return Spring Guide Rod (requires 1 Nut, Part Number RD-60033-10 SOLD SEPARATELY) (RD10/15)
$37.00 -
RD-00318 Steel Clamp Bar with Holes for Holding Die (RD10/15)
$122.00 -
RD-00341 Hub Plain - NO Detent (RD10/15)
$72.00 -
RD-00342 Die Shaft - 14 Inches Long x 5/8 OD (RD10)
$16.00 -
RD-00358 Support Arm (RD10/15)
$226.00 -
RD-00363 Brass Gib Casting - OLD Style - Used with RD00312 (RD10/15)
$165.00 -
RD-00376 Length of Stroke Screw - No Hole (RD10/15)
$58.00 -
RD-00377 Tie Rod - 1 Inch Diameter & Short Threads (RD10/15)
$165.00 -
RD-00388 Steel Back-Up Bar for Brass Gib - Used with RD00394 (RD10/15)
$15.00 -
RD-00390 Lower Pivot Block (RD10)
$408.00 -
RD-00391 Pivot Pin (RD10/15)
$52.20 -
RD-00392 Upper Pivot Block Support (RD10/15)
$92.00 -
RD-00393 Bevel Washer - Used with Tie Rods RD00377 & RD 00378 (RD10/15)
$13.05 -
RD-00394MA Brass Gib - NEW Style CHANNEL (RD10/15)
$360.25 -
RD-00396 Stop Block (RD10/15)
$125.00 -
RD-00413 Brass Coupling (RD10/15)
$28.00 -
RD-00414 Positioning Plate - Clamp Bar (RD10/15)
$21.00 -
RD-00415 Clevis Pins (RD10/15)
$8.00 -
RD-00417 Leveling Pads (RD10/15)
$25.65 -
RD-00418 Depth-of-Stroke Screw with Hole for Counter Cable (RD10/15)
$75.00
