Triplex "S" Slip & Drive Cutting Attachment
The Lockformer Triplex Slitting Attachment is an optional tool that can be mounted to the Triplex Cleatformer. The Slitting Attachment has two (2) sets of cutting wheels that are used to cut material and automatically feed into the “S” Cleat Rolls and Drive Cleat Rolls. With use, it is common to replace these cutting wheels as they will become dull and nicked up over time. Please review the parts list to find the replacement parts you require or contact if you need assistance.
Triplex "S" Slip & Drive Cutting Attachment
-
L-11711 B1 Slitting Roll
$345.10 -
L-11712 T1 Slitting Roll
$208.50 -
L-13287 T1 Roll Shaft
$457.61 -
L-13288 B1 Roll Shaft
$457.61 -
L-13702 Spacer
$117.38 -
L-14150 Drive Gear
$248.13 -
L-14171 Idler Gear
$202.58 -
L-14226 Clutch, Gear
$364.60 -
L-19332 Deflector Spacer
$66.09 -
L-21304 Entrance Gauge Bar
$131.02 -
L-34700 Deflector Guard
$51.09 -
L-34960 Wear Plate
$52.45 -
L-35322 Cover Plate
$103.14 -
L-35902 Wear Plate
$102.65 -
L-35979 Slitter Template
$92.48 -
L-39976 Thrust Washer
$56.75 -
L-40250-01 Slitter Housing
$2,430.76 -
L-42401 Woodruff Key
$24.81 -
L-44021 Bearing, Thrust Washer
$48.05 -
L-50993 Order New Part #35322
-
L-52907 Entrance Gauge Bar
$178.50 -
L-52963 Entrance Table Weldment
$456.79 -
L-56574 Deflector Assembly
$483.86 -
L-56895 Deflector Weldment
$357.44
