Roper Whitney Connecticut U422 Box & Pan Bench Brake

Manufacturer: Roper Whitney

Condition: NEW

Location: F.O.B Factory

Description:

Connecticut bench mounted hand brakes are rugged, dependable USA-made tools. The model U422 is a heavy duty bench brake suitable for box and pan or straight bending up to 22-gauge mild steel. The brake features a removable apron angle and apron insert permitting 1/4-inch reverse bends in lighter materials. The front to rear adjust- ment of the U422 allows for a wide range of radius bending. Standard equipment includes: an apron stop rod for repeat bends, extension handles and counterweight to help reduce fatigue when using the brake. The lighter weight makes this model better suited for transporting to remote job sites. Connecticut bench-mounted hand brakes provide an economical means of performing a wide range of sheet metal bending and forming operations. These brakes are of all- steel welded construction, readily adjustable and backed by an industry leading 3-Year Factory Warranty.

Description

Connecticut bench mounted hand brakes are rugged, dependable USA-made tools. The model U422 is a heavy duty bench brake suitable for box and pan or straight bending up to 22-gauge mild steel. The brake features a removable apron angle and apron insert permitting 1/4-inch reverse bends in lighter materials. The front to rear adjust- ment of the U422 allows for a wide range of radius bending.

Standard equipment includes: an apron stop rod for repeat bends, extension handles and counterweight to help reduce fatigue when using the brake. The lighter weight makes this model better suited for transporting to remote job sites.

Connecticut bench-mounted hand brakes provide an economical means of performing a wide range of sheet metal bending and forming operations. These brakes are of all- steel welded construction, readily adjustable and backed by an industry leading 3-Year Factory Warranty.

specifications

Weight - 280 lbs

Dimensions - 61 x 20 x 28 in

Bending length - 48 in/ 1220 mm

Capacity mild steel, 1 inch flange, with bending bar and angle in place - 22 ga/ 0.76 mm

Minimum reverse bend (bar and angle removed) - 5/16 in/ 7.95 mm

Maximum life of beam - 7/8 in/ 22 mm

Finger widths - 2, 3 and 4 in/ 51, 76 and 101 mm

Maximum depth of box - 3 in/ 76mm

Front to rear adjustment - 1/4 in/ 6.35 mm

Bench stand (optional) - 56″ long, 18″ wide, 26″ high

accessories

Optional Bench Stand Available
