TK Edgenotcher

Manufacturer: Tin Knocker

Condition: NEW

Location: F.O.B Factory

Description:

The Tin Knocker Edge Notcher is designed to notch the edges of sheet metal quickly, accurately, and automatically. The Edge notcher is equipped with power-driven feed rolls and a guide assembly for precision in automatically feeding and controlling metal through the notching dies. Edge Notcher – a valuable addition to any sheet metal shop. Capable of notching round surfaces as well as straight for maximum flexibility.

Description

The Tin Knocker Edge Notcher is designed to notch the edges of sheet metal quickly, accurately, and automatically. The Edge notcher is equipped with power-driven feed rolls and a guide assembly for precision in automatically feeding and controlling metal through the notching dies. Edge Notcher – a valuable addition to any sheet metal shop. Capable of notching round surfaces as well as straight for maximum flexibility.

specifications

  • Motor: 1/3 HP, 110 V, single phase, 60Hz, AC
  • Depth of Notch: 0 to 3/4 in
  • Width of Notch: 3/16 in
  • Spacing: 3/4 in. to 1 7/16 in
  • Capacity: 20 gauge m. s.
  • Speed: Variable Minimum 18 FPM
  • Overall dimensions: 21 in. long, 16 1/2 in. high, 13 in. deep
  • Approx. Shipping Weight: 290 lbs
