Tennsmith F6-72-12 Box & Pan Hand Brake

Manufacturer: Tennsmith

Condition: NEW

Location: F.O.B Factory

Description:

TENNSMITH’S F6 Series box and pan brakes were designed to provide heavy-duty forming capability, along with the flexibility of removable 6-inch box depth fingers. Ample clamping and easy-to-use nose bar adjustments allow for a quick-setting bend radius. Welded steel plate construction and heavy truss rods and braces provide strength and rigidity.

Description

TENNSMITH’s F6 Series box and pan brakes were designed to provide heavy-duty forming capability, along with the flexibility of removable 6-inch box depth fingers.

Ample clamping and easy-to-use nose bar adjustments allow for a quick-setting bend radius. Welded steel plate construction and heavy truss rods and braces provide strength and rigidity.



Other adjustment features include:

•Leveling screws and lock nuts on the pedestals

•Jack screws and tensioner bolts on the apron

•Truss rods on the apron, base and upper beam

•Fully adjustable counter balances to facilitate the bending process

•Removable apron angle and insert permit 1/4-inch reverse bends in lighter material

specifications

Capacity, mild steel - 12 gauge/2.7 mm

Capacity, stainless steel - 16 gauge/1.6 mm

Bending length - 72 in./1829 mm

Maximum Iift of beam - 2-1/4 in./57 mm

Front to rear beam adjustment - 1/2 in./12.7 mm

Maximum depth of box - 6 in./152.4 mm

Minimum reverse bend - 1/4 in./6 mm

Minimum flange in capacity material - 1 in./25 mm

Finger widths - 3, 4 and 5 in. / 76.3, 101.6 and 127 mm

Dimensions, counterweights in place, LxWxH -110 x 53 x 60 in. / 2794 x 1347 x 1524 mm

Shipping weight - 2825 Ibs./1282 kg

features

  • Leveling screws and lock nuts on the pedestals
  • Jack screws and tensioner bolts on the apron
  • Truss rods on the apron, base and upper beam
  • Fully adjustable counter balances to facilitate the bending process
  • Removable apron angle and insert permit 1/4-inch reverse bends in lighter material
